HIMA F3331 Module

HIMA HIMATRIX F3331 One Year Warranty

brand:
HIMA DCS
item no:
F3331
payment:
T/T, Western Union, Credit Card
product origin:
Germany
good stock:
6.0
shipping port:
Saudi Arabia
lead time:
1-3 Working Days
condition:
Brand New And Original
warranty:
12 Months
certificate:
COO
description:
8 Fold Output Module

Product Details
FAQs

HIMA HIMATRIX F3331 Output Module

F3331 Appertaining function block: HB-BLD-3 or HB-BLD-4

The module is automatically tested during operation. The main test routines are:– Reading back of the output signals. The operating point of the 0-signal read back is≤ 6.5 V. Up to this value the level of the 0-signal may arise in case of a fault and thiswill not be detected– Switching capability of the test signal and cross-talking (walking-bit test)Outputs 500 mA, short-circuit proofInternal voltage drop max. 2 V at 500 mA loadAdmissible line resistance (in + out) max. 11 ΩUndervoltage tripping at ≤ 16 VOutput leakage current max. 350 µAOutput voltage if output is reset max. 1.5 VCurrent input WD max. 30 mAMonitored switching time max. 200 µsSpace requirement 4 SUOperating data 5 VDC / 130 mA24 VDC / 180 mA plus load

Hima Main Serise:

1. CPU: F8650X, F8650E, F8641
2. Power Distribution Module: F7130A, F7130, F7131, F7133
3. Communication MODULE Coprocessor MODULE； F8621A, F8627X, F8628, F8628X

4. Input Module: F3221, F3222, F3223, F3224, F3236, F3237, F6208, F6214, F6215, F6216, F6216A, F6217, F6220, F6221
5. OUTPUT MODULE: F3330, F3331, F3332, F3333, F3334, F3322, F7126, F6705, F1DI1601, F3DIO8/801, F2DO1602, F3DIO20/802, F3AIO8/401, F60GEH01, F60PS01, F60DIO24/1601, F60DI3201, Z7116, Z7126, Z7127, Z7138, Z7128
6. I/O bus link module block: F7553
